1、 Keel device

1、玻鎂防火板覆蓋的墻面須按規劃圖或施工圖的要求裝置龍骨，并對龍骨進行調平處理。龍骨外表應平整、光滑、無銹蝕、無變形。

1. The wall covered by glass magnesium fireproof board shall be equipped with keel according to the requirements of the planning drawing or construction drawing, and the keel shall be leveled. The keel surface shall be flat, smooth, free of rust and deformation.

2、龍骨間隙內需要填充物的，應按規劃要求先行裝置、處理，并保證不影響玻鎂防火板的裝置。

2. If fillers are needed in the keel gap, they shall be installed and treated first according to the planning requirements, and ensure that the installation of glass magnesium fireproof board will not be affected.

3、結構墻體要依照建筑規范進行施工前處理，龍骨的排布尺度必定要和玻鎂的排布相適應。木龍骨距離應小于300mm，輕鋼龍骨距離不大于400mm。龍骨的裝置應與玻鎂長度方向相垂直。

3. The structural wall shall be treated before construction in accordance with the building code, and the layout scale of keel must adapt to the layout of glass magnesium. The distance between wood keels shall be less than 300mm, and the distance between light steel keels shall not be more than 400mm. The device of keel shall be perpendicular to the length direction of glass magnesium.

4、木龍骨外表到基層的距離依照具體要求，一般為50mm。木龍骨邊面平整度及垂直度差錯應不大于0.5mm。

4. The distance from the wooden keel surface to the base course is generally 50mm according to specific requirements. The error of flatness and perpendicularity of the edge surface of wooden dragon bone shall not be greater than 0.5mm.

二、面板裝置

2、 Panel device

1、測量墻面尺度，確認裝置方位，確認水平線和垂直線，確認電線插口、管子等物體的切空預留尺度。

1. Measure the wall scale, confirm the device orientation, confirm the horizontal line and vertical line, and confirm the cut-off reserved scale of wire socket, pipe and other objects.

2、按施工現場的實踐尺度計算并裁開部分玻鎂(對立面上有對稱要求的，特別要注意裁開部分玻鎂的尺度，保證兩頭的對稱)和線條(收邊線條、外角線條、銜接線條)，并為電線插口、管子等物體切空預留。

2. Calculate and cut some glass magnesium according to the practical scale of the construction site (if there are symmetry requirements on the opposite facade, pay special attention to the scale of cutting some glass magnesium to ensure the symmetry of both ends) and lines (edge closing lines, outer corner lines, connecting lines), and reserve space for wire sockets, pipes and other objects.

3、裝置玻鎂防火板

3. Device glass magnesium fireproof board

(1)玻鎂防火板的裝置次序，遵從從左到右、從下到上的準則。

(1) The installation sequence of glass magnesium fireproof board shall follow the guidelines from left to right and from bottom to top.

(2)玻鎂防火板橫向裝置時，凹口朝上;豎直裝置時，凹口在右側。

(2) When the glass magnesium fireproof board is installed horizontally, the notch faces upward; When the device is vertical, the notch is on the right.

(3)部分玻鎂防火板有對斑紋要求的，每一立面應依照玻鎂上事前編制好的編號順次從小到大進行裝置。(玻鎂的編號遵從從左到右、從下到上、數字順次從小到大)

(3) If some glass magnesium fireproof boards have requirements for speckle, each facade shall be installed from small to large according to the number prepared in advance on glass magnesium. (the number of glass magnesium follows from left to right, from bottom to top and from small to large in sequence)

4、對玻鎂防火板有收邊要求時，收邊線條對其進行收邊，收邊處用螺釘固定。對右側、上側的收邊線條裝置時為橫向脹大預留1.5mm，并可選用硅膠密封。

4. When there are edge trimming requirements for glass magnesium fireproof board, the edge trimming line shall be used for edge trimming, and the edge trimming part shall be fixed with screws. For the edge closing line device on the right and upper sides, 1.5mm is reserved for transverse expansion, and silicone sealing can be selected.

5、玻鎂在龍骨上的固定用射釘裝置沿企口及板槽處用射釘將玻鎂固定在龍骨上，射釘須有2/3 以上嵌入木龍骨，射釘要均勻排布，并要求有必定的密度，每塊玻鎂防火板與每條龍骨上聯合射釘數量不少于10 個。

5. The fixation of glass magnesium on the keel shall be fixed on the keel with shooting nails along the groove and groove. More than 2 / 3 of the shooting nails must be embedded in the wooden keel. The shooting nails shall be evenly arranged and required to have a certain density. The number of combined shooting nails on each glass magnesium fireproof board and each keel shall not be less than 10.

6、檢修孔及其他施工問題

6. Manhole and other construction problems

(1)檢修孔在同一平面時，檢修孔蓋板除木收邊外的其余外表要貼玻鎂做裝修;墻面的玻鎂在檢修孔處不收邊，只需要和檢修孔邊際齊平即可。

(1) When the manhole is on the same plane, the surface of the manhole cover plate shall be decorated with glass magnesium except for wood trimming; The glass magnesium on the wall does not close at the manhole, but only needs to be flush with the edge of the manhole.

(2)如檢修孔的方位和玻鎂施工墻面垂直觸摸，應要求更改檢修孔的方位，保證玻鎂的施工條件。

(2) If the orientation of the manhole is perpendicular to the construction wall of glass magnesium, the orientation of the manhole shall be changed as required to ensure the construction conditions of glass magnesium.
