Composite wallboard is a new generation of high-performance building internal partition. It replaces the traditional brick and tile. It has the advantages of environmental protection, energy conservation, no pollution, fire prevention and thermal insulation, sound insulation and earthquake resistance. What are the specifications of composite wallboard and how to install it? If you are interested, let's get to know it with the European School Xiaobian.

復合墻板是新一代高性能建筑內隔板，它代替了傳統的磚瓦，具有環保節能無污染，防火保溫，隔音抗震等優點。那么復合墻板規格多少以及如何安裝呢？>復合墻板規格多少

Composite wallboard is a new generation of high-performance building internal partition. It replaces the traditional brick and tile. It has the advantages of environmental protection, energy conservation, no pollution, fire prevention and thermal insulation, sound insulation and earthquake resistance. What are the specifications of composite wall panels and how to install them? > What is the specification of composite wallboard

復合墻板規格有很多，不同種類的復合墻板其規格也各不相同。

There are many specifications of composite wallboards, and the specifications of different types of composite wallboards are also different.

彩鋼復合墻板厚度有50mm、75mm、100mm等，其芯層有巖棉、泡沫兩類。巖棉一般使用密度有80公斤/立方米、100公斤/立方米、120公斤/立方米、140公斤/立方米、160公斤/立方米、180公斤/立方米；泡沫一般使用密度有6公斤/立方米、8公斤/立方米、10公斤/立方米等。上下彩鋼防腐層保持期為10-15年，彩色鍍鋁鋅防腐層保持為30-45年，彩鋼板厚度為0.17-0.6mm之間。

The thickness of color steel composite wallboard is 50mm, 75mm, 100mm and so on. The core layer has two types: rock wool and foam. The general use density of rock wool is 80kg / m3, 100kg / m3, 120kg / m3, 140kg / m3, 160kg / m3 and 180kg / m3; The general density of foam is 6 kg / cubic meter, 8 kg / cubic meter, 10 kg / cubic meter and so on. The retention period of upper and lower color steel anticorrosive coatings is 10-15 years, the retention period of color aluminum zinc anticorrosive coatings is 30-45 years, and the thickness of color steel plates is between 0.17-0.6mm.

鋁塑復合墻板的厚度，常見是3-10mm，標準長度是2440mm，非標準可以加長到6000mm多，當然也可以短于1000mm，標準寬度一般均是1220mm，也有1000mm，寬可以做到2000mm。

The thickness of aluminum-plastic composite wallboard is usually 3-10mm, the standard length is 2440mm, non-standard can be extended to more than 6000mm, of course, it can also be shorter than 1000mm, the standard width is generally 1220mm, there are also 1000mm, and the maximum width can be 2000mm.

聚氨酯復合墻板容重范圍為40-60kg/m3,長度范圍是0.5-4m，寬度范圍為0.5-1.2m，厚度范圍為20-200mm，切割精度高，厚度誤差是0.5mm左右。

The unit weight range of polyurethane composite wallboard is 40-60kg / m3, the length range is 0.5-4m, the width range is 0.5-1.2m, the thickness range is 20-200mm, the cutting accuracy is high, and the thickness error is about 0.5mm.

復合墻板怎么安裝呢？

How to install the composite wallboard?

1、首先是要看好設計圖紙，根據放樣的設計圖紙來進一步的確定木榫的尺寸以及規格，然后在根據設計圖紙來確定墻面彈線、復合墻板加工地。

1. First of all, we should pay attention to the design drawings, further determine the size and specification of the wooden tenon according to the setting out design drawings, and then determine the wall snapping line and the processing place of the composite wallboard according to the design drawings.

2、鉆孔固定需要使用的是60*M8的膨脹螺絲來做一個穩固，在使用十二毫米的鉆頭來進行打孔，孔的深度大概在四十五毫米之間。

2. The 60 * M8 expansion screw shall be used for drilling fixation to make a firm. A 12mm drill bit shall be used for drilling, and the depth of the hole is about 45mm.

3、將60*M8的膨脹螺絲放到孔里，如果施工的現場已經進行到了預埋階段的話，需要對復合墻板隔斷軸線的位置放好定位線，然后固定好地面裝飾表面水平和軸線基準點。

3. Put the 60 * M8 expansion screw into the hole. If the construction site has reached the embedding stage, it is necessary to set the positioning line at the position of the partition axis of the composite wallboard, and then fix the ground decoration surface level and axis reference point.

4、同時還需要對輕質隔墻板每個跨度之間尺寸的復核，經過仔細確認好之后在根據設計圖紙立柱水平間距在對預埋件進行防銹處理的分布，符合要求之后在使用膨脹螺絲來穩固。

4. At the same time, it is also necessary to recheck the size between each span of the light partition board. After careful confirmation, the expansion screw shall be used to stabilize the embedded parts after the distribution of anti rust treatment according to the horizontal spacing of columns in the design drawing meets the requirements.
